Trusted Partner For Medical Vet Equipment Needs
Syringe Pump for Veterinary Use
• Automatic recognition of syringe sizes (5, 10, 20, 30, and 50/60) • Open system, and stores up to 20 editable brands • 4.3 inch color touch screen, parameter setting and editing directly • Multi-function operation with 3 modes: ml/h (time, rate mode); Body-weight mode and Micro-mode • Flow rates range from 0.01ml/h to 1,500ml/h with increment of 0.01ml/h • KVO range from 0.01 to 5ml/h, editable • Optional wireless connection to our C7 Central Station • History record more than 5000 logs • 12 hours battery back-up time • IP24 waterproof, and stackable design
Special Features
Basic Parameter
Didistribusikan Oleh PT. Inter Med Solution Kawasan Bussines Link Citra Raya S.05/291 Tangerang -BANTEN
This compact device ESP-7 Smart Syringe Pump works both on battery and mains supply, which is perfecly adapted for veterinary use. Our multi-function syringepump brings a whole new array of features and benefits for your day to day fluid therapy requirements.
Screen 4.3 inch LCD color touch screen.
Syringe Types 5ml, 10ml, 20ml, 30ml, 50/60ml Open system, automatic recognition of syringe brands and sizes after calibration.
Infusion mode ml/h (Include Rate mode, Time mode) Body weight mode.
Accuracy +2%.
Flow Rate Range 0.01-1500ml/h (min. increment 0.01ml/h).
VTBI 0-9999 ml.
KVO 0.01-5ml/h adjustable.
Bolus Rate 0.01-1500ml/h (automatic & manual bolus available).
Occlusion Level 4 levels selectable.
Interface MINI USB.
Wireless Wifi (optional).
Alarm Type VTBI Infused, Syringe empty, Pressure high, Battery empty, Check srynge, KVO finished, VTBI near and, Syringe near empty, Battery near empty, Reminder alarm, No power supply, System error, etc.
Titration Change flow rate without stopping infusion.
Last Therapy Last therapies can be stored and used for rapid infusion.
Drug Library No less than 30 drugs.
Anti-Bolus Automatic drop line pressure to reduce bolus impact after occlusion.
Purge Remove the air bubble.
Screen Lock Avoid misoperation.
Standby Mode Standby time 00-99h59m adjustable.
Micro Mode Limit the max infusion rate to double ensure patient safety.
DPS Real-time pressure display in graphically and numerically.
Brightness Adjustable.
Alarm Volume Adjustable.
History Record More than 5000 entries.
Power Source
AC Power 110V-240V, 50/60Hz.
External DC Power 12V.
Battery Lithium Polymer battery 11.1V 2600mAh. More than 12 hours operating time @ 5ml/h. Less than 5 hours for fully changed.
Others
Classification Class l, CF.
Waterproof IP24.
Dimansion 400(L)*90(W)*120(H) mm (with cover). 235(L)*90(W)*120(H) mm (without cover).
Weight Approx 1.7kg.
